Fe-Si powder is an iron-silicon power consists of 6.5% silicon (Si). It's charactorized itself with very high saturation density (up to 16,000 Gauss), superior DC bias performance, high energy storage capacity as well as good temperature stability. It also delivers lower loss than iron powder. Mirrack's Fe-Si (MKF)'s permeabilities range from 26u to 90u. It's alternatively named as XFlux by Magnetics, or Mega Flux by Chung Sung (CSC), or Fluxsan by Arnold.

It's widely used in the renewable energies such as solar / PV, wind energy and hybrid powered vehicles as well as telecommunications' power supplies, server power supplies, UPS, etc., serving as power factor correction choke (PFC choke), switching regulator inductor, high current power choke, power inductor for energy storage, output inductor for general industrial power supplies, in-line noise filter / EMI filter.

● Stable quality and good conformity

Mirrack Part No.	Before Coating						After Coating						Electromagnetic Property		Inch Reference No.	Specification download
	OD(MAX)		ID(MIN)		HT(MAX)		OD(MAX)		ID(MIN)		HT(MAX)		Perm.	AL
	Inch	mm	Inch	mm	Inch	mm	Inch	mm	Inch	mm	Inch	mm	[μ]	nH/ N2 (+/-8%)
MKF066-026	0.260	6.600	0.105	2.67	0.100	2.54	0.285	7.24	0.085	2.16	0.125	3.18	26	11	027026	download
MKF066-060	0.260	6.600	0.105	2.67	0.100	2.54	0.285	7.24	0.085	2.16	0.125	3.18	60	26	027060	download
MKF066-075	0.260	6.600	0.105	2.67	0.100	2.54	0.285	7.24	0.085	2.16	0.125	3.18	75	32	027075	download
MKF066-090	0.260	6.600	0.105	2.67	0.100	2.54	0.285	7.24	0.085	2.16	0.125	3.18	90	39	027090	download
MKF078-026	0.310	7.87	0.156	3.96	0.125	3.18	0.335	8.51	0.135	3.43	0.150	3.81	26	11	031026	download
MKF078-060	0.310	7.87	0.156	3.96	0.125	3.18	0.335	8.51	0.135	3.43	0.150	3.81	60	25	031060	download
MKF078-075	0.310	7.87	0.156	3.96	0.125	3.18	0.335	8.51	0.135	3.43	0.150	3.81	75	31	031075	download
MKF078-090	0.310	7.87	0.156	3.96	0.125	3.18	0.335	8.51	0.135	3.43	0.150	3.81	90	37	031090	download
MKF096-026	0.380	9.65	0.188	4.78	0.125	3.18	0.405	10.29	0.168	4.27	0.150	3.81	26	11	039026	download
MKF096-060	0.380	9.65	0.188	4.78	0.125	3.18	0.405	10.29	0.168	4.27	0.150	3.81	60	25	039060	download
MKF096-075	0.380	9.65	0.188	4.78	0.125	3.18	0.405	10.29	0.168	4.27	0.150	3.81	75	32	039075	download
MKF096-090	0.380	9.65	0.188	4.78	0.125	3.18	0.405	10.29	0.168	4.27	0.150	3.81	90	38	039090	download
MKF097-026	0.380	9.65	0.188	4.78	0.156	3.96	0.405	10.29	0.168	4.27	0.181	4.60	26	14	038026	download
MKF097-060	0.380	9.65	0.188	4.78	0.156	3.96	0.405	10.29	0.168	4.27	0.181	4.60	60	32	038060	download
MKF097-075	0.380	9.65	0.188	4.78	0.156	3.96	0.405	10.29	0.168	4.27	0.181	4.60	75	40	038075	download
MKF097-090	0.380	9.65	0.188	4.78	0.156	3.96	0.405	10.29	0.168	4.27	0.181	4.60	90	48	038090	download
MKF102-026	0.400	10.20	0.200	5.08	0.156	3.96	0.425	10.80	0.180	4.57	0.181	4.60	26	14	040026	download
MKF102-060	0.400	10.20	0.200	5.08	0.156	3.96	0.425	10.80	0.180	4.57	0.181	4.60	60	32	040060	download
MKF102-075	0.400	10.20	0.200	5.08	0.156	3.96	0.425	10.80	0.180	4.57	0.181	4.60	75	40	040075	download
MKF102-090	0.400	10.20	0.200	5.08	0.156	3.96	0.425	10.80	0.180	4.57	0.181	4.60	90	48	040090	download
MKF112-026	0.440	11.20	0.250	6.35	0.156	3.96	0.468	11.89	0.232	5.89	0.186	4.72	26	11	044026	download
MKF112-060	0.440	11.20	0.250	6.35	0.156	3.96	0.468	11.89	0.232	5.89	0.186	4.72	60	26	044060	download
MKF112-075	0.440	11.20	0.250	6.35	0.156	3.96	0.468	11.89	0.232	5.89	0.186	4.72	75	32	044075	download
MKF112-090	0.440	11.20	0.250	6.35	0.156	3.96	0.468	11.89	0.232	5.89	0.186	4.72	90	38	044090	download
MKF127-026	0.500	12.70	0.300	7.62	0.187	4.75	0.530	13.46	0.275	6.99	0.217	5.51	26	12	050026	download
MKF127-060	0.500	12.70	0.300	7.62	0.187	4.75	0.530	13.46	0.275	6.99	0.217	5.51	60	27	050060	download
MKF127-075	0.500	12.70	0.300	7.62	0.187	4.75	0.530	13.46	0.275	6.99	0.217	5.51	75	34	050075	download
MKF127-090	0.500	12.70	0.300	7.62	0.187	4.75	0.530	13.46	0.275	6.99	0.217	5.51	90	40	050090	download
MKF166-026	0.650	16.50	0.400	10.20	0.250	6.35	0.680	17.40	0.375	9.53	0.286	7.11	26	15	065026	download
MKF166-060	0.650	16.50	0.400	10.20	0.250	6.35	0.680	17.40	0.375	9.53	0.286	7.11	60	35	065060	download
MKF166-075	0.650	16.50	0.400	10.20	0.250	6.35	0.680	17.40	0.375	9.53	0.286	7.11	75	43	065075	download
MKF166-090	0.650	16.50	0.400	10.20	0.250	6.35	0.680	17.40	0.375	9.53	0.286	7.11	90	52	065090	download
MKF172-026	0.680	17.30	0.380	9.65	0.250	6.35	0.710	18.03	0.355	9.02	0.280	7.11	26	19	068026	download
MKF172-060	0.680	17.30	0.380	9.65	0.250	6.35	0.710	18.03	0.355	9.02	0.280	7.11	60	43	068060	download
MKF172-075	0.680	17.30	0.380	9.65	0.250	6.35	0.710	18.03	0.355	9.02	0.280	7.11	75	53	068075	download
MKF172-090	0.680	17.30	0.380	9.65	0.250	6.35	0.710	18.03	0.355	9.02	0.280	7.11	90	64	068090	download
MKF203-026	0.800	20.30	0.500	12.70	0.250	6.35	0.830	21.10	0.475	12.07	0.280	7.11	26	14	080026	download
MKF203-060	0.800	20.30	0.500	12.70	0.250	6.35	0.830	21.10	0.475	12.07	0.280	7.11	60	32	080060	download
MKF203-075	0.800	20.30	0.500	12.70	0.250	6.35	0.830	21.10	0.475	12.07	0.280	7.11	75	41	080075	download
MKF203-090	0.800	20.30	0.500	12.70	0.250	6.35	0.830	21.10	0.475	12.07	0.280	7.11	90	49	080090	download
MKF229-026	0.900	22.90	0.550	14.70	0.300	7.62	0.930	23.62	0.527	13.3	0.330	8.38	26	19	090026	download
MKF229-060	0.900	22.90	0.550	14.70	0.300	7.62	0.930	23.62	0.527	13.3	0.330	8.38	60	43	090060	download
MKF229-075	0.900	22.90	0.550	14.70	0.300	7.62	0.930	23.62	0.527	13.3	0.330	8.38	75	54	090075	download
MKF229-090	0.900	22.90	0.550	14.70	0.300	7.62	0.930	23.62	0.527	13.3	0.330	8.38	90	65	090090	download
MKF234-026	0.928	23.60	0.567	14.40	0.350	8.89	0.956	24.30	0.542	13.77	0.382	9.7	26	22	092026	download
MKF234-060	0.928	23.60	0.567	14.40	0.350	8.89	0.956	24.30	0.542	13.77	0.382	9.7	60	51	092060	download
MKF234-075	0.928	23.60	0.567	14.40	0.350	8.89	0.956	24.30	0.542	13.77	0.382	9.7	75	63	092075	download
MKF234-090	0.928	23.60	0.567	14.40	0.350	8.89	0.956	24.30	0.542	13.77	0.382	9.7	90	76	092090	download
MKF270-026	1.060	26.90	0.580	14.70	0.440	11.20	1.090	27.70	0.555	14.10	0.472	11.99	26	32	106026	download
MKF270-060	1.060	26.90	0.580	14.70	0.440	11.20	1.090	27.70	0.555	14.10	0.472	11.99	60	75	106060	download
MKF270-075	1.060	26.90	0.580	14.70	0.440	11.20	1.090	27.70	0.555	14.10	0.472	11.99	75	94	106075	download
MKF270-090	1.060	26.90	0.580	14.70	0.440	11.20	1.090	27.70	0.555	14.10	0.472	11.99	90	113	106090	download
MKF270H-026	1.060	26.90	0.580	14.70	0.340	8.64	1.090	27.70	0.555	14.10	0.372	9.45	26	22	107026	download
MKF270H-060	1.060	26.90	0.580	14.70	0.340	8.64	1.090	27.70	0.555	14.10	0.372	9.45	60	59	107060	download
MKF270H-075	1.060	26.90	0.580	14.70	0.340	8.64	1.090	27.70	0.555	14.10	0.372	9.45	75	74	107075	download
MKF270H-090	1.060	26.90	0.580	14.70	0.340	8.64	1.090	27.70	0.555	14.10	0.372	9.45	90	89	107090	download
MKF330-026	1.300	33.00	0.785	19.90	0.420	10.70	1.332	33.83	0.760	19.30	0.457	11.61	26	28	130026	download
MKF330-060	1.300	33.00	0.785	19.90	0.420	10.70	1.332	33.83	0.760	19.30	0.457	11.61	60	61	130060	download
MKF330-075	1.300	33.00	0.785	19.90	0.420	10.70	1.332	33.83	0.760	19.30	0.457	11.61	75	76	130075	download
MKF330-090	1.300	33.00	0.785	19.90	0.420	10.70	1.332	33.83	0.760	19.30	0.457	11.61	90	91	130090	download
MKF330H-026	1.300	33.00	0.785	19.90	0.345	8.76	1.332	33.83	0.760	19.30	0.382	9.70	26	22	131026	download
MKF330H-060	1.300	33.00	0.785	19.90	0.345	8.76	1.332	33.83	0.760	19.30	0.382	9.70	60	51	131060	download
MKF330H-075	1.300	33.00	0.785	19.90	0.345	8.76	1.332	33.83	0.760	19.30	0.382	9.70	75	64	131075	download
MKF330H-090	1.300	33.00	0.785	19.90	0.345	8.76	1.332	33.83	0.760	19.30	0.382	9.70	90	76.5	131090	download
MKF343-026	1.350	34.30	0.920	23.40	0.350	8.89	1.382	35.10	0.888	22.56	0.387	9.83	26	16	135026	download
MKF343-060	1.350	34.30	0.920	23.40	0.350	8.89	1.382	35.10	0.888	22.56	0.387	9.83	60	38	135060	download
MKF343-075	1.350	34.30	0.920	23.40	0.350	8.89	1.382	35.10	0.888	22.56	0.387	9.83	75	47	135075	download
MKF343-090	1.350	34.30	0.920	23.40	0.350	8.89	1.382	35.10	0.888	22.56	0.387	9.83	90	57	135090	download
MKF358-026	1.410	35.80	0.880	22.40	0.412	10.50	1.442	36.63	0.848	21.54	0.444	11.28	26	24	141026	download
MKF358-060	1.410	35.80	0.880	22.40	0.412	10.50	1.442	36.63	0.848	21.54	0.444	11.28	60	56	141060	download
MKF358-075	1.410	35.80	0.880	22.40	0.412	10.50	1.442	36.63	0.848	21.54	0.444	11.28	75	70	141075	download
MKF358-090	1.410	35.80	0.880	22.40	0.412	10.50	1.442	36.63	0.848	21.54	0.444	11.28	90	84	141090	download
MKF400-026	1.570	39.90	0.950	24.10	0.570	14.50	1.602	40.72	0.918	23.30	0.605	15.37	26	35	157026	download
MKF400-060	1.570	39.90	0.950	24.10	0.570	14.50	1.602	40.72	0.918	23.30	0.605	15.37	60	81	157060	download
MKF400-075	1.570	39.90	0.950	24.10	0.570	14.50	1.602	40.72	0.918	23.30	0.605	15.37	75	101	157075	download
MKF400-090	1.570	39.90	0.950	24.10	0.570	14.50	1.602	40.72	0.918	23.30	0.605	15.37	90	121	157090	download
MKF467-026	1.840	46.70	0.950	24.10	0.710	18.00	1.875	47.63	0.918	23.32	0.745	18.92	26	59	184026	download
MKF467-060	1.840	46.70	0.950	24.10	0.710	18.00	1.875	47.63	0.918	23.32	0.745	18.92	60	135	184060	download
MKF467-075	1.840	46.70	0.950	24.10	0.710	18.00	1.875	47.63	0.918	23.32	0.745	18.92	75	169	184075	download
MKF467-090	1.840	46.70	0.950	24.10	0.710	18.00	1.875	47.63	0.918	23.32	0.745	18.92	90	202	184090	download
MKF468-026	1.840	46.70	1.130	28.70	0.600	15.20	1.875	47.63	1.098	27.89	0.635	16.13	26	37	185026	download
MKF468-060	1.840	46.70	1.130	28.70	0.600	15.20	1.875	47.63	1.098	27.89	0.635	16.13	60	86	185060	download
MKF468-075	1.840	46.70	1.130	28.70	0.600	15.20	1.875	47.63	1.098	27.89	0.635	16.13	75	107	185075	download
MKF468-090	1.840	46.70	1.130	28.70	0.600	15.20	1.875	47.63	1.098	27.89	0.635	16.13	90	128	185090	download
MKF508-026	2.000	50.80	1.250	31.80	0.530	13.50	2.035	51.69	1.218	30.94	0.565	14.35	26	32	200026	download
MKF508-060	2.000	50.80	1.250	31.80	0.530	13.50	2.035	51.69	1.218	30.94	0.565	14.35	60	73	200060	download
MKF508-075	2.000	50.80	1.250	31.80	0.530	13.50	2.035	51.69	1.218	30.94	0.565	14.35	75	91	200075	download
MKF508-090	2.000	50.80	1.250	31.80	0.530	13.50	2.035	51.69	1.218	30.94	0.565	14.35	90	109	200090	download
MKF571-026	2.250	57.20	1.039	26.40	0.600	15.20	2.285	58.00	1.007	25.60	0.635	16.10	26	60	226026	download
MKF571-060	2.250	57.20	1.039	26.40	0.600	15.20	2.285	58.00	1.007	25.60	0.635	16.10	60	138	226060	download
MKF571-075	2.250	57.20	1.039	26.40	0.600	15.20	2.285	58.00	1.007	25.60	0.635	16.10	75	175	226075	download
MKF571-090	2.250	57.20	1.039	26.40	0.600	15.20	2.285	58.00	1.007	25.60	0.635	16.10	90	207	226090	download
MKF572-026	2.250	57.20	1.400	35.60	0.550	14.00	2.285	58.00	1.368	34.70	0.585	14.86	26	33	225026	download
MKF572-060	2.250	57.20	1.400	35.60	0.550	14.00	2.285	58.00	1.368	34.70	0.585	14.86	60	75	225060	download
MKF572-075	2.250	57.20	1.400	35.60	0.550	14.00	2.285	58.00	1.368	34.70	0.585	14.86	75	94	225075	download
MKF572-090	2.250	57.20	1.400	35.60	0.550	14.00	2.285	58.00	1.368	34.70	0.585	14.86	90	112	225090	download
MKF610-026	2.441	62.00	1.283	32.60	0.984	25.00	2.484	63.10	1.235	31.37	1.034	26.27	26	83	250026	download
MKF610-060	2.441	62.00	1.283	32.60	0.984	25.00	2.484	63.10	1.235	31.37	1.034	26.27	60	192	250060	download
MKF610-075	2.441	62.00	1.283	32.60	0.984	25.00	2.484	63.10	1.235	31.37	1.034	26.27	75	240	250075	download
MKF610-090	2.441	62.00	1.283	32.60	0.984	25.00	2.484	63.10	1.235	31.37	1.034	26.27	90	288	250090	download
MKF777-026	3.063	77.80	1.938	49.20	0.500	12.70	3.108	78.90	1.898	48.20	0.545	13.84	26	30	300026	download
MKF777-060	3.063	77.80	1.938	49.20	0.500	12.70	3.108	78.90	1.898	48.20	0.545	13.84	60	68	300060	download
MKF777-075	3.063	77.80	1.938	49.20	0.500	12.70	3.108	78.90	1.898	48.20	0.545	13.84	75	85	300075	download
MKF777-090	3.063	77.80	1.938	49.20	0.500	12.70	3.108	78.90	1.898	48.20	0.545	13.84	90	102	300090	download
MKF778-026	3.063	77.80	1.938	49.20	0.625	15.90	3.108	78.90	1.898	48.20	0.670	17.02	26	37	301026	download
MKF778-060	3.063	77.80	1.938	49.20	0.625	15.90	3.108	78.90	1.898	48.20	0.670	17.02	60	85	301060	download
MKF778-075	3.063	77.80	1.938	49.20	0.625	15.90	3.108	78.90	1.898	48.20	0.670	17.02	75	107	301075	download
MKF778-090	3.063	77.80	1.938	49.20	0.625	15.90	3.108	78.90	1.898	48.20	0.670	17.02	90	128	301090	download
MKF1016-026	4.000	101.60	2.250	57.15	0.650	16.51	4.050	103.12	2.195	55.75	0.700	17.78	26	47	400026	download
MKF1016-060	4.000	101.60	2.250	57.15	0.650	16.51	4.050	103.12	2.195	55.75	0.700	17.78	60	112	400060	download
MKF1016-075	4.000	101.60	2.250	57.15	0.650	16.51	4.050	103.12	2.195	55.75	0.700	17.78	75	137	400075	download
MKF1016-090	4.000	101.60	2.250	57.15	0.650	16.51	4.050	103.12	2.195	55.75	0.700	17.78	90	164	400090	download
